DALI Dimmer Universal | for LED

Compatible with most well-known brands like Gira, Berker & Jung. Can be ordered in combination with white plate art. 215-132 Featuring: • Built-in on/off and rotary knob dimming control • Overheating protection • Smooth dimming compatible with most LED fittings Description- Dimmer for DALI dimmable Driver Electrical Characteristics- Output DALI signal Product Name 215-134 Input Parameters Rated Input Voltage Uin 220-240VAC Input Current (Full load) Iin 15mA Input Frequency fin 50/60Hz Maximum Input Power Pin 1.6W No-load power ≤0.3W Output Parameters Output Voltage Vout 17±0.5V Output Current (Full load) Iout 52mA Output Power (Full load) Pout 0.6W Operating Frequency(Full load) Fout MAX number of driver connected to the dimmer 26pcs Dimming range 1…100% Storage Temperature ts -20 … 70℃ Operating Ambient Temperature ta -20 … 45℃ Case Temperature at tc Point tc 85℃ Relative humidity 5 …85% Protection Over Current Auto-recovery if fault is removed Over Voltage Auto-recovery if fault is removed Short Circuit System Parameters Weight 120g Dimensions(LxWxH)： 83.5×83.5x44mm Compliances and approvals Safety CE SKU: TRX-215-134 Categories: DALI LED lighting, LED Switches/Controllers, Wall Sockets & Switches Brand: Tronix
