Digital Foam Resilience Tester

Digital Foam Resilience Tester is designed according to ISO 8307 and ASTM D 3574 test standards . It through specify diameter and mass ball fall on the foam specimen from certain height, calculate the percentage between maximum drop height and rebound height, indicate foam resilience by spring rate. It uses PLC control, LCD display and with USB port(Optional) to output test results. Standard : ISO8307, ASTM D 3574 Drop height（adjustable） 500±0.5%mm(ASTM) Ball diameter ￠16±0.05 mm Accuracy <1.5% Display LCD Touch Screen interface Test result Average rebound height, average spring rate Dimension (L×W×H)100 mm×100 mm× 50mm Power AC240V±10%, 50/60Hz, single phase Notice: JavaScript is required for this content.
